The Scheppach WSE 1000 inverter welder is a compact, lightweight, easy-to-use, and powerful welding machine suitable for welding tasks in garages, workshops around the house, cottages, etc. It comes in a practical set that includes everything you need to start welding immediately - a cable with grounding clamps, a cable with electrode holder, a protective shield, a slag hammer with a wire brush, 3x welding electrodes, a shoulder strap, and a foldable handle for easy transport. The machine is equipped with efficient cooling, overheating protection, and overload protection with a light indication. The welding current can be adjusted gradually by a rotary controller in the range of 10 to 130 A. The machine has been tested with excellent results by Czech professional welders and specialized welding equipment dealers. Thanks to the latest technologies that facilitate welding, it is suitable not only for skilled welders but also for absolute beginners.
ARC FORCE - A function that helps stabilize the burning electric arc during welding. If the arc shortens (electrode sticks), the welder "adds" current and the electrode burns off. If, on the other hand, the arc is too long, the welder "reduces" the current, giving the welder time to bring the electrode closer to the material without extinguishing the arc.
ANTI STICK - If the electrode does stick, this function ensures a sudden reduction of the welding current to a minimum. The electrode does not ignite but cools down, making it easy to detach without the need to remove it from the clamps.
HOT START - A function that facilitates arc ignition by increasing the ignition current by approximately 30% compared to the current set by the welder. After successful ignition, the current decreases to the value set by the welder.
Accessories range:
shoulder strap
cable with grounding clamps
cable with electrode holder
Grounding cable: 1.5 m
Welding cable: 2 m
Power cable: 3 m
slag hammer with wire brush
welding shield
Technical parameters
| Operating voltage |
230 V, 50 Hz |
| No-load voltage |
85 V |
| Welding method |
MMA (manual metal arc welding, all types) |
| Application |
all weldable metal materials, steel, cast iron, non-ferrous metals, etc. |
| Welding current range |
10 – 130 A, continuous |
| Welding electrode diameter |
1.6 to 3.2 mm |
| Functions |
Arc Force, Anti Stick, Hot Start |
| Protection class |
IP 21S |
| Fuse |
16 A |
| Min. working time |
100%-65A / 60%-85A / 25%-130A |
